Product Features
★ High-precision bipolar power output
★ High-precision real-time monitoring of output voltage and current
★ Two output modes: constant voltage and constant current
★ Global shutdown and local shutdown functions
★ Synchronous triggering function enables simultaneous changes to the output
★ USB and RS232 interfaces enable programmable control
★ Equipped with fully functional host computer software
Application scenarios
★ Semiconductor chip characteristics and leakage current testing
★ Testing of optoelectronic devices and optical communication components
★ Performance Testing of New Energy Storage Devices
★ Precision Measurement in the Laboratory
Product Features
★ High-precision bipolar power output
★ High-precision real-time monitoring of output voltage and current
★ Two output modes: constant voltage and constant current
★ Global shutdown and local shutdown functions
★ Synchronous triggering function enables simultaneous changes to the output
★ USB and RS232 interfaces enable programmable control
★ Equipped with fully functional host computer software
Application scenarios
★ Semiconductor chip characteristics and leakage current testing
★ Testing of optoelectronic devices and optical communication components
★ Performance Testing of New Energy Storage Devices
★ Precision Measurement in the Laboratory
Project | Unit | Index |
Output voltage range | In | ±12 |
Output current range | m.a. | ±200 |
Number of output channels | 104 | |
Output voltage Resolution | mV | 1 |
Output voltage accuracy | mV | 5 |
Output voltage Linearity | mV | 1 |
Real-time voltage measurement accuracy | mV | 5 |
Real-time current measurement Resolution | m.a. | 0.1 |
Real-time current measurement accuracy | m.a. | 0.1 |
Communication interface | USB/RS232 | |
Power supply method | AC 100～250V | |
Operating temperature | ℃ | -10~+50 |
Storage temperature | ℃ | -20~+70 |
Storage humidity | ≤90%RH | |
Size | mm | 450x480x132 (Length x Width x Height) |
Weight | kg | ≈8.2 |
